Page 301 - Tecnoinox CUCINE MODULARI

33080 PORCIA ITALY - VIA TORRICELLI 1
Tel: +39.0434.920110 - Fax: +39.434.920422 LISTINO PREZZI 2019
tecnoinox@tecnoinox.it PRICE LIST
www.tecnoinox.it
Cappe | Hoods
AISI304 CAPPA A PARETE CON ASPIRATORE INCORPORATO, FILTRI A LABIRINTO IN ACCIAIO INOX, COMPLETAMENTE SALDATA E CON ILLUMINAZIONE AD
INCASSO
WALL-MOUNTED HOOD, FULL WELDED BODY WITH EXTRACTION FAN UNIT, STAINLESS STEEL LABYRINTH FILTERS AND BUILT-IN LIGHTING.

Portata nom.
Dimensioni / Dimensions cm Filtri /Filters HST Aspiratore / Electric motor
CODE Model Nom. capacity EURO
3
A × B × H C × D E N dim. m /h Pa W A Mod.
515001 TSPM9/12 90 × 120 × 45 23 × 21 24 2 40×50 1400 180 184 1,8 7/7 2.287,00
515002 TSPM9/16 90 × 160 × 45 23 × 21 24 3 40×50 1600 160 184 1,8 7/7 2.521,00
515003 TSPM9/18 90 × 180 × 45 23 × 21 24 3 40×50 1800 100 184 1,8 7/7 2.775,00
515004 TSPM9/20 90 × 200 × 45 30 × 26 24 4 40×50 2200 230 420 3,8 9/9T 2.947,00
515005 TSPM9/24 90 × 240 × 45 30 × 26 24 4 40×50 2400 210 420 3,8 9/9T 3.225,00
515006 TSPM9/28 90 × 280 × 45 30 × 26 24 5 40×50 2600 180 420 3,8 9/9T 3.604,00
515007 TSPM9/30 90 × 300 × 45 30 × 26 24 6 40×50 2800 150 420 3,8 9/9T 3.725,00
515008 TSPM11/12 110 × 120 × 45 23 × 21 24 2 40×50 1400 180 184 1,8 7/7 2.340,00
515009 TSPM11/16 110 × 160 × 45 23 × 21 24 3 40×50 1600 160 184 1,8 7/7 2.702,00
515010 TSPM11/18 110 × 180 × 45 23 × 21 24 3 40×50 1800 100 184 1,8 7/7 2.958,00
515011 TSPM11/20 110 × 200 × 45 30 × 26 24 4 40×50 2200 230 420 3,8 9/9T 3.166,00
515012 TSPM11/24 110 × 240 × 45 30 × 26 24 4 40×50 2400 210 420 3,8 9/9T 3.447,00
515013 TSPM11/28 110 × 280 × 45 30 × 26 24 5 40×50 2600 180 420 3,8 9/9T 3.981,00
515014 TSPM11/30 110 × 300 × 45 30 × 26 24 6 40×50 2800 150 420 3,8 9/9T 4.115,00
515015 TSPM14/12 140 × 120 × 45 23 × 21 24 2 40×50 1400 180 184 1,8 7/7 2.629,00
515016 TSPM14/16 140 × 160 × 45 23 × 21 24 3 40×50 1600 160 184 1,8 7/7 2.934,00
515017 TSPM14/18 140 × 180 × 45 23 × 21 24 3 40×50 1800 100 184 1,8 7/7 3.214,00
515018 TSPM14/20 140 × 200 × 45 30 × 26 24 4 40×50 2200 230 420 3,8 9/9T 3.421,00
515019 TSPM14/24 140 × 240 × 45 30 × 26 24 4 40×50 2400 210 420 3,8 9/9T 3.823,00
515020 TSPM14/28 140 × 280 × 45 30 × 26 24 5 40×50 2600 180 420 3,8 9/9T 4.357,00
515021 TSPM14/30 140 × 300 × 45 30 × 26 24 6 40×50 2800 150 420 3,8 9/9T 4.443,00

NOTE:
• Per lunghezze diverse considerare il prezzo della cappa immediatamente più lunga. / For other lenghts consider the price of hoods with next lenghts up.
• Imballo in gabbia di legno compreso nel prezzo. / Packaging by wooden cage included in the price.
• In dotazione rubinetto scarico grassi e kit per fissaggio a parete. / Equipped with tap for fat discharge and wall brackets.

ACCESSORI A RICHIESTA | OPTIONAL EXTRAS ON REQUEST CODE Model EURO
Regolatore elettronico digitale di velocità, con interrut-
tori motore, luce e con comando per eventuale valvola
gas centrale. - Electronic and digital speed regulator fe- 592001 TRE600 238,00
aturing switches for motor, light and device for eventual
central gas valve.

299
